High rate electrolyte used in aeromodelling and electric tool
Name
High rate electrolyte used in aeromodelling and electric tool
Specifications and Other Information of Our High rate electrolyte used in aeromodelling and electric tool
Detailed Specification
Grade 1
| Electrolyte grade | WI206 | ||
| Warranty period | 6 months(Unopened) | Cathode material | LCO,LCO+NMC |
| Solvent composition | EC/DMC/EMC | Anode material | Artificial graphite |
| Moisture content | ≤15ppm | Rate performance | It can satisfy 5-10C fast charging, 20-30C high magnification discharge and capacity play is more than 90%, platform is more than 3.35v |
| Density | >1,15g/mL | Rate Cycle performance | It Cycled at 15-30C and after 300 Cycles, the capacity retentions is more than 90% |
| Acidity content | ≤50ppm | Applicable battery | Soft package |
| Density | >1,25g/mL | Low temperature performance | Under -20℃, Capacitance play is more than 80% at 0.2C |
| Conductivity | 10.0-12.0ms/cm | Chroma | ≤50Hazen |
| High temperature performance | Under 60℃ and for 7 days with full charge, the expansion rate is less than 5%, capacity recovery rate is more than 90% at 20-30C | ||
Grade 2
| Electrolyte grade | WI506 | ||
| Warranty period | 6 months(Unopened) | Cathode material | LCO |
| Solvent composition | EC/EMC/DMC/EA/PC | Anode material | Artificial graphite |
| Moisture content | ≤15ppm | Rate performance | It can satisfy 5-10C fast charging, 30-60C high magnification discharge and capacity play is more than 90%, platform is more than 3.35v |
| Density | >1,20g/mL | Rate Cycle performance | It Cycled at 15-30C and after 300 Cycles, the capacity retentions is more than 90% |
| Acidity content | ≤50ppm | Applicable battery | Soft package |
| Conductivity | 10.0-12.0ms/cm | Chroma | ≤50Hazen |
| Low temperature performance | Under -20℃ and for 16 hours, discharge capacity is more than 90% at 0.3C, The battery does not bilge gas when charging at 0.5C-1C under -20℃-10℃ | ||
Advantage
This series of electrolyte is mainly aimed at the aeromodelling, electric tool andother multiplicative electrolyte, which can make the battery have better multiplier performance.
General View of Documents
Links
This product is developed by our R&D company Warshel Chemical Ltd(http://www.warshel.com/), and here is the corresponding linkhttp://www.warshel.com/high-rate-electrolyte-used-in-aeromodelling-and-electric-tool/
